Roadster

Hunter 350

FUSE & CARRIER

  • Fuse & Fuse carrier located in RH side cover.

WARNING

  • Please get the electrical system of your motorcycle checked thoroughly and get the faults corrected immediately after experiencing any fuse failure. Failure to do so many result in repeated fuse failure.

  • Usage of fuses other than specified rating will damage the complete electrical system.

NOTE

  • F2- Device bt + fuse -25 A - EMS ECU. Instrument cluster. Tripper.

  • F3 -Ignition fuse (EFI) -15 A- Relay Coil. EMS ECU. Ignition Coil. Fuel pump. Injector. 02 Sensor. E purge and diagnostic tool. F4 -Signalling fuse -10 A-Instrument cluster. Tripper. Gear Position Sensor. Flasher. Brake Switch and Horn.

  • F6- Lighting fuse -15 A-Headlamp low & high beam. Front position lamp. Rear position lamp & License plate illuminator. Please ensure to replace a spare fuse in the holder at the earliest opportunity.
S. NO.DESCRIPTIONPERIODICAL MAINTENANCE (Whichever is earlier)
 Km (x1000)0.55101520253035404550
 Months1.56121824303642485460
1Engine Oil (Level check/replace)RIRIRIRIRIR
Check level at every 1,000 km or earlier and top up as required
2Engine oil filter elementR R R R R R
3Engine oil strainer on crankcase LHC C C C C C
4Inlet/exhaust tappet setting  I&A I&A I&A I&A I&A
5Rubber hose-intake adapterIIIIIIIIIII
6Evaporative emission equipment rubber hoses & drain the overfilled by removing plug IIIIIIIIRII
7Spark plug  C&A R C&A R C&A
8HT lead for crackIIIIIIIIIII
9Air filter elementCCRCRCRCRCR
Clean / Replace more frequently if operated in dusty condition
10Vent pipe under air filter boxIIIIIIIIIII
11Starter motor & starter relay connectionIIIIIIIIIII
12Battery terminals (apply petroleum jelly)CCCCCCCCCCC
13Earth wire eyelet contact    I     I
14Injector HorseIIIIIIIIIII
15Fuel filter in fuel pump      R
16Front fork oil IIIIRIIIRII
17Steering ball races playInspect & adjust, if required lubricate for every 5,000 Km every service or earlier as required. Replcae if necessary
18Spokes tightness/wheel rim run out front & rearI I I I I I
19Swing arm pivot bush & spacerIInspect & if required lubricate for every 5,000 km or earlier as required. Replace if necessary
20Tyre wear pattern (front & rear)IIIIIIIIIII
21Rear wheel drive chainClean, lubricate every 500 km / clean, lubricate & adjust every 5,000 km or earlier as required
22Rear wheel cush drive rubbers    I&R   I&R
23Front & rear brake hose & banjo boltIIIIIIIIIII
24Brake fluid level, front & rear discIIIIRIIIRII
25Clutch lever / cable free playAdjust every 1,000 km or earlier as required & replace if required
26Hand levers & foot leversLubricate every 1,000 km or earlier as required.
27Pivot side stand, center stand, pillion foot rest, gear shifter, brake pedal, leversLLLLLLLLLLL
28Throttle cableAdjust every 5,000 km or earlier if required
29Brake pads - front & rearIIIIIIIIIII
30Side stand switch operationIIIIIIIIIII
31All mounting fasteners in vehicle for tightnessIIIIIIIIIII
32Throttle body - cleaningThrottle body should be removed from the vehicle and cleaned with a dry microfibre cloth, usage of throttle body cleaners or any similar solvent or alcohol based liquids for cleaning is strictly prohibited, Throttle body cleaning every 10,000 km / 12 months or earlier as required.

A : Adjust C : Clean I : Inspect (Clean, Adjust, Lubricate or replace if necessary) L : Lubricate R : Replace



NOTE - For maintenance after 50,000 km, please repeat the same frequency specified above, in consultation with a Royal Enfield Authorised Dealer / Service Centre.
