Roadster

Hunter 350

FUSE & CARRIER

  • The fuse carrier is located underneath rider seat.

  • Insert ignition key and turn it anticlockwise.

  • Remove the pillion and rider seat outside for opening the same.

WARNING

  • Please get the electrical system of your motorcycle checked thoroughly and get the faults corrected immediately after experiencing any fuse failure. Failure to do so many result in repeated fuse failure.

  • Usage of fuses other than specified rating will damage the complete electrical system.

  • Please ensure to replace a spare fuse in the holder at the earliest opportunity.

  • Any attempt to jumper a defective fuse gives rise to the risk of a short-circuit and fire. Always replace a defective fuse with a new fuse of the same rating.

NOTE

  • Make sure the ignition switch is in OFF position when replacing the bulbs, fuses and electrical parts.

S. NO.DESCRIPTIONPERIODICAL MAINTENANCE (Whichever is earlier)
 Km (x1000)0.55101520253035404550
 miles (x1000)0.336912151821242730
 Months1.56121824303642485460
1Engine Oil (#)R R R R R R
Check level at every 1000 km or earlier and top up as required
2Engine Oil (#)R R R R R R
3Inlet and exhaust valve clearance  I I I I I
4Spark PlugIIIIRIIIRII
5HT LeadIIIIIIIIIII
66 Rubber hose, Air filter to throttle bodyIIIIIIIIIII
7Rubber hose, Inlet manifold / AdapterIIIIIIIIIII
8Evaporative emission equipment rubber hosesIIIIIIIIIII
9Fuel filter external    R   R
10Air filter elementCCRCRCRCRCR
Clean / Replace more frequently if operated in dusty condition
11Vent pipe under air filter boxIIIIIIIIIII
12Accelerator and throttle pulley cables free playAAAAAAAAAAA
13Clutch cable / lever free playAdjust every 1000 km or earlier as required
14Hand levers pivot pointLubricate every 1000 km or earlier as required
15Brake pads - Front and RearIIIIIIIIIII
16Disc brake fluid level - Front and RearIIIIRIIIRII
17Rear brake pedal and gear change pedal pivotLLLLLLLLLLL
18Brake hose and banjo bolt - Front and rearIIIIIIIIIII
19Headstock bearingsIIIIIIIIIII
20Rear wheel drive chainLubricate and adjust every 1000 km/clean, lubricate and adjust
every service or earlier as required
21Rear wheel cush rubbers   I   I
22Spokes tightness/wheel rim run out front and rear
(It is applicable for spokes wheel model)
IIIIIIIIIII
23Battery terminals (apply petroleum jelly)IIIIIIIIIII
24Earth wire eyelet tightness  I I I I I
25Tyre wear pattern front and rearIIIIIIIIIII
26Pivot-side standLLLLLLLLLLL
27Rider and pillion footrest pivotLLLLLLLLLLL
28All mounting fasteners in vehicle for tightness**IIIIIIIIIII

A : Adjust C : Clean I : Inspect (Clean, Adjust, Lubricate or replace if necessary) L : Lubricate R : Replace

(#) - After first service, engine oil and engine oil filter replacement is a mandatory at every 12 months even the vehicle has not covered the specified kilometre.

(**) - If any fastener found loose tighten to the specified torque.

NOTE -For maintenance after 50,000 km, please repeat the same frequency specified above, in consultation with a Royal Enfield

Authorised Dealer / Service Centre.
