FUSE & CARRIER

  • The fuse carrier is located inside the left side panel.

  • Insert ignition key and turn it clockwise.

  • Pull the side panel outside for opening the same.

WARNING

  • Please get the electrical system of your motorcycle checked thoroughly and get the faults corrected immediately after experiencing any fuse failure. Failure to do so many result in repeated fuse failure.

  • Usage of fuses other than specified rating will damage the complete electrical system.

  • Please ensure to replace a spare fuse in the holder at the earliest opportunity.

  • Any attempt to jumper a defective fuse gives rise to the risk of a short-circuit and fire. Always replace a defective fuse with a new fuse of the same rating.

NOTE

  • Make sure the ignition switch is in OFF position when replacing the bulbs, fuses and electrical parts.

S. NO.DESCRIPTIONPERIODICAL MAINTENANCE (Whichever is earlier)
 Km (x1000)0.55101520253035404550
 Months1.56121824303642485460
1Engine Oil (#)R R R R R R
Check level at every 1000 km or earlier and top up as required
2Engine Oil Filter (#)R R R R R R
3Inlet and exhaust valve clearance  I I I I I
4Spark PlugIIIIRIIIRII
5HT LeadIIIIIIIIIII
6Rubber hose, Air filter to throttle bodyIIIIIIIIIII
7Rubber hose, Inlet manifold / AdapterIIIIIIIIIII
8Evaporative emission equipment rubber hosesIIIIIIIIIII
9Air filter elementCCRCRCRCRCR
Clean / Replace more frequently if operated in dusty condition
10Vent pipe under air filter boxIIIIIIIIIII
11Throttle cableAAAAAAAAAAA
12Clutch cable / lever free playAdjust every 1000 km or earlier as required
13Clutch lever & front brake lever pivotsLubricate every 1000 km or earlier as required
14Brake pads - Front and RearIIIIIIIIIII
15Brake fluid - Front and RearIIIIRIIIRII
16Rear brake pedal and gear change pedal pivotLLLLLLLLLLL
17Brake hose and banjo bolt - Front and rearIIIIIIIIIII
18Headstock bearingsIIIIIIIIIII
19Rear wheel drive chain

                                                                                          Clean, lubricate and adjust every 500 km or earlier as required or

                                                                                                          after riding in wet/dusty/muddy conditions

20Rear wheel cush rubbers    I   I
21Battery terminals (apply petroleum jelly)IIIIIIIIIII
22Spokes tightness/wheel rim run out front and rearIIIIIIIIIII
23Earth wire eyelet tightness  I I I III
24Tyre wear pattern front and rearIIIIIIIIIII
25Side stand & center stand pivotsLLLLLLLLLLL
26Rider and pillion footrest pivotLLLLLLLLLII
27All mounting fasteners in vehicle for tightnessIIIIIIIIIII

A : Adjust C : Clean I : Inspect (Clean, Adjust, Lubricate or replace if necessary) L : Lubricate R : Replace

(#) - After first service, engine oil and engine oil filter replacement is required every 12 months regardless of kilometres.

(**) - After first service, valve clearance adjustment is required every 12 months regardless of kilometre.

NOTE - For maintenance after 50,000 km, please repeat the same frequency specified above, in consultation with a Royal Enfield

Authorised Dealer / Service Centre.
