FUSE & CARRIER

  • Fuse & Fuse carrier located in RH side cover.

WARNING

  • Please get the electrical system of your motorcycle checked thoroughly and get the faults corrected immediately after experiencing any fuse failure. Failure to do so many result in repeated fuse failure.

  • Usage of fuses other than specified rating will damage the complete electrical system.

NOTE

  • F2- Device bt + fuse -10 A - EMS ECU. Instrument cluster. Tripper.

  • F3 -Ignition fuse (EFI) -15 A- Relay Coil. EMS ECU. Ignition Coil. Fuel pump. Injector. 02 Sensor. E purge and diagnostic tool. F4 -Signalling fuse -15 A-Instrument cluster. Tripper. Gear Position Sensor. Flasher. Brake Switch and Horn.

  • F6- Lighting fuse -15 A-Headlamp low & high beam. Front position lamp. Rear position lamp & License plate illuminator. Please ensure to replace a spare fuse in the holder at the earliest opportunity.
